Connect and go with the ProLite T2234AS-B1, the all-in-one monitor solution for shops, retail or information desks. The HDMI output makes it easy to connect a second customer-facing display for dynamic content and advertising.
The robust screen comes with a rugged bezel and an IP65 rating, meaning the monitor is dust and water resistant from the front. Cables can be neatly tied with the special cable cover, so they cannot come loose or move around. Featuring IPS LCD screen technology, it offers exceptional colour performance and wide viewing angels, making it a perfect interactive display for in-store retail.
IPS
IPS displays are best known for wide viewing angles and natural, highly accurate colours. They are especially suited for colour-critical applications.
TECHNICAL SPECIFICATION
| Design |
Edge to edge glass |
| Diagonal |
21.5", 55cm |
| Panel |
IPS LED |
| Native resolution |
1920 x 1080 (2.1 megapixel Full HD) |
| Aspect ratio |
16:9 |
| Brightness |
350 cd/m² typical |
| Brightness |
305 cd/m² with touch |
| Static contrast |
1000:1 with touch |
| Light transmittance |
87% |
| Response time (GTG) |
8ms |
| Viewing zone |
horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° |
| Colour support |
16.7mln 8bit |
| Viewable area W x H |
476.6 x 268.1mm, 18.8 x 10.6" |
| Pixel pitch |
0.247mm |
| Bezel colour and finish |
black, matte |
| Touch technology |
projective capacitive |
| Touch points |
10 |
| Touch method |
finger, glove (latex), capacitive stylus |
| Touch interface |
USB |
| Supported operating systems |
All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Digital signal output |
HDMI x1 (1920 x 1080 @60Hz) |
| Audio output |
Speakers 2 x 2W |
| USB ports |
x4 (2.0 x 3, 2.0 with OTG x1) |
| RS-232c |
x1 |
| RJ45 (LAN) |
x1 |
| Integrated software |
Android 8.1 without GMS |
| CPU |
Rockchip RK3288, quad-core Cortex--A17 up to 1.8GHz |
| GPU |
Mail-T760 MP4 |
| Storage |
16GB eMMC |
| Memory |
2GB DDR3 |
| WiFi |
IEE802.11b/g/n |
| Bluetooth |
4.0 |
| Extra |
SD card slot, anti-fingerprint coating |
| Max. non-stop operating time |
24/7 |
| Glass thickness |
2.5mm |
| Glass hardness |
7H |
| Water and dust protection |
IP65 (front) |
| OSD key lock |
yes |
| Applications |
install or uninstall, calculator, calendar, clock and alarm, manage contact information, manage emails, manage files, view photo album, web browser (Lightning), play audio files, update system online, search engine, system preferences, sound recorder, play video files, web browser (WebView) |
| Orientation |
landscape, portrait, face-up |
| Tilt angle |
90° up; 5° down |
| VESA mounting |
100 x 100mm |
| Cable management system |
yes |
| Guides |
quick start guide, safety guide |
| Other |
AC adapter |
| Cable cover |
yes |
| Power supply unit |
external |
| Power supply |
DC 12 V |
| Power usage |
25W typical, 0.5W off mode |
| Regulations |
CE, RoHS support, ErP, WEEE, CU, cULus, REACH, CCC |
| Other |
REACH SVHC above 0.1%: Lead |
| Product dimensions W x H x D |
517.5 x 351.5 x 219mm |
| Box dimensions W x H x D |
615 x 450 x 330mm |
| Pallet volume |
24pcs |
| Pallet dimensions W x H x D |
1090 x 2110 x 1090mm |
| Weight (without box) |
6.6kg |
| EAN code |
4948570117178 |
