Hikvision Tripod turnstile DS-K3G411-R/E-Dm55 + Integrated EM scanner

€2,299.00

Turime daug

Value Tripod Turnstile Bidirectional (Entering/Exiting) lane Lane width: 550mm Integrated EM scanner For inside use TCP/IP network communication: The communication data is specially encrypted to relieve the concern of privacy leak Barrier open/closed, free accessing,...

Value Tripod Turnstile

  • Bidirectional (Entering/Exiting) lane
  • Lane width: 550mm
  • Integrated EM scanner
  • For inside use
  • TCP/IP network communication: The communication data is specially encrypted to relieve the concern of privacy leak
  • Barrier open/closed, free accessing, forbidden mode are selectable
  • Bidirectional (Entering/Exiting) lane
  • Remote control and management
  • LED indicates the entrance/exit and passing status.
  • Fire alarm passing: When the fire alarm is triggered, the barrier will be dropped automatically for emergency evacuation.
  • Valid passing duration settings: System will cancel the passing permission if a person does not pass through the lane within the valid passing duration

Description

  • System
  • MCBF>3 million times
  • Interface
  • Lock control2
  • Alarm input2
  • Alarm output2
  • Network interface1
  • RS-4856 (The interfaces can be switched to RS-232 via DIP switch)
  • RS-232

    6 interfaces can be switched to RS-232 via DIP switch;

    2 for fingerprint module or QR code scanner

  • Capacity
  • Card capacity60,000
  • Event capacity180,000
  • General
  • Throughput

    More than 35 persons per minute

    The actual throughput is affected by the person passing rate and passing method.

  • Power supply method100 to 240 VAC; 50 to 60 Hz
  • Working temperature-10 °C to 50 °C (14 °F to 122 °F)
  • Lane width550mm
  • Working humidity0% to 95% (No condensing)
  • Pedestal materialSUS304 stainless steel
  • Dimensions

    Without package: 502 mm × 202 mm × 1010 mm (19.8" × 8.0\" × 40.0\")

    With package: 745 mm × 365 mm × 1120 mm (29.3 × 14.4\" × 44.1\")"

  • Application environmentIndoor
  • Without package: 26 kg (57.3 lb)

    With package: 31 kg (68.41 lb)

  • ApprovalCE/FCC/CB/RoHS/REACH/WEEE
  • Configuration
  • Module selectionYES
  • Authentication modeCard;Face;QR code;Fingerprint
  • Authentication exclusionaryFingerprint;QR code
  • Card typeEM;M1
  • Wall distance20mm
  • Lane width550
  • Pedestal width202 mm
  • Pedestal length502 mm
  • Barrier materialStainless steel pipe
  • BaseYES
  • Side pedestalYES
  • Base modelDS-K3G411-BASE
  • Side pedestal typefence(130mm)
